GNSS - SL869-V3

The SL869-V3 is designed without compromises to deliver the best pure GNSS tracking performance. The SL869-V3 is equipped with the ST Microelectronic Teseo III core and is able to track GPS, Glonass, Beidou and Galileo constellations. It supports A-GNSS onboard generation as well as A-GNSS server-generated file injection.

The SL869-V3 includes a number of communication ports like UART, I2C. The I2C port is available to support external sensors.

The embedded flash memory allows firmware upgrades and customization.

The embedded TCXO ensures stable top tier performance over the entire temperature range.

The Jupiter SL869-V3 is as a pure GNSS sibling module of the SL869-ADR. The SL869-V3 is also pin-to-pin compatible with the SL869 and SL869-V2. While SL869-ADR is equipped with Dead Reckoning software and internal 6-axis MEMS sensor, the SL869-V3 is equipped with a pure GNSS navigation engine without embedded MEMS to provide a low cost solution that enable customer to scale down the application keeping the same command interface at the SL869-ADR.

The SL869-V3 is an ideal platform for high demanding applications like Automotive, Telematics, Metering.

FAMILY CONCEPT

The xL869 is Telit’s GNSS Unified Form Factor family which allows customers to select among different GNSS technol-ogies. Modules in this family are offered in a 16 x 12.2 mm, 24-pad, LCC package supporting GPS, GLONASS, Galileo, and QZSS constellations.

Our positioning product portfolio is the result of over twenty years of experience in GNSS applications. Telit has developed a range of products compatible with the well-known GPS constellation as well as its Russian counterpart GLONASS. Moreover, our portfolio is fully aligned with the upcoming service launch of Europe’s Galileo constella-tion. Valuable features such as Dead Reckoning, Precision Timing, as well as speed and reliability assured by multi-constellation coverage, provide additional benefits for your application.

Your application development effort can also benefit sig-nificantly from the seamless integration between Telit’s cellular and positioning modules. This bundling of cellular and positioning modules significantly reduces develop-ment complexity without adding costs. Multi-constellation positioning products applied together with our eCall / ERA-GLONASS compliant cellular modules bring you ready-to-use emergency automotive tracking solutions for the European and Russian markets.

Typical applications include fleet management systems, European GPS-assisted road tolling systems, cellular base stations, in-car navigation systems, automotive telematics-systems, and GPS-based personal sports training monitors.

MARKET SEGMENT

• Automotive
• Telematics

KEY FEATURES

• GPS, Glonass, Galileo and Beidou compatible
• 16 x 12.2 x 2.4 mm LLC package
• Supply voltage range: 3 - 3.6 VDC
• Assisted GPS
• 10Hz Navigation, SBAS, 1PPS
• UART, I2C
