LTE 2G Terminals -

GE910T-QUAD

The GE910T-QUAD terminal is a comple-te encased modem solution which combi-nes the access to digital communication services in GSM, GPRS networks.

GE910T-QUAD includes features like EGPRS Class 33, Analog voice interface, circuit switched data transfer, phonebook and SMS support, embedded TCP/IP protocol stack and custom Telit AT commands.

GE910T-QUAD offers extended operating temperature, integrated TCP/IP stack, direct control by standard serial RS-232 interface or USB 2.0 interface, and with a broad supply voltage range (5-32 V DC), the GE910T-QUAD Terminal is a complete stand alone solution for m2m applications that require high speed data exchange.

GE910T-QUAD is provided with Windows and Linux drivers that signifcantly ease the integration in existing applications.

GE910T-QUAD, support Over-the-Air firmware update by means Premium FOTA Management.

GE910T-QUAD can be provided with Windows, Linux and WinCE CDC Serial USB drivers and also with Modem Dri-vers.

GL865T-DUAL

The GL865T-DUAL terminal is a complete encased modem solution which combines the access to digital communication servi-ces in GSM and GPRS networks.

GL865T-DUAL is the new generation based on the dual-band and RoHS comliant GL865 core engine incorporating additional and new features.

The GL865T-DUAL featuring the embedded Python™ script interpreter provides the possibility for running customer programs inside the modem, thus making the terminal a complete self-contained application platform for customer solutions. Program-mable I/O port, RS232 port and Serial Debug Port can be used for monitoring external signals, connecting sensors, and switc-hing external devices. The GL865T-DUAL offers jamming detection functionality allowing the unit to sense attempts to disrupt the GSM communication by interference with the GSM signal.

GL865T-DUAL offers extended operating temperature, integrated TCP/IP stack,direct control by standard serial RS-232 interface and with a broad supply voltage range (5-32 VDC - Min1.2A), the GL865T-DUAL terminal is a complete stand alone solution for m2m applications.

GL865T-DUAL, supports Over-the-Air firmware update by means Premium FOTA Management. By embedding RedBend’s vCur-rent® agent, a proven and battle-tested technology powering hundreds of millions of cellular handsets world-wide is able to updateits products by transmitting only a delta file, which represents the difference between one firmware version and anot-her.

GE864T-GPS

GE864T-GPS GSM/GPRS/GPS terminal is the new generation based on the Quad-Band and RoHS comliant GE864 core engine incorporating additional and new features.

The GE864T-GPS featuring the embedded Python™ script interpreter provides the possibility for running customer programs inside the modem, thus making the terminal a complete self-contained application platform for customer solutions. Program-mable I/O port, RS232 port and Serial Second GPS Port can be used for monitoring external signals, connecting sensors, and switching external devices. The GE864T-GPS offers jamming detection functionality allowing the unit to sense attempts to dis-rupt the GSM communication by interference with the GSM signal.

GE864T-GPS offers extended operating temperature, integrated TCP/IP stack,direct control by standard serial RS-232 interface and with a broad supply voltage range (5-32 VDC - Min1.2A), the GE864T-GPS terminal is a complete stand alone solution for m2m applications.

GE864T-GPS Terminal is integrating full 48-channels A-GPS functionality. It combines the high performance from Telit's proven GSM/GPRS core technology with the latest SiRFstarIV™ high sensitivity single-chip A-GPS receiver.

GE864T-GPS, supports Over-the-Air firmware update by means Premium FOTA Management. By embedding RedBend’s vCur-rent® agent, a proven and battle-tested technology powering hundreds of millions of cellular handsets world-wide is able to updateits products by transmitting only a delta file, which represents the difference between one firmware version and anot-her.

Terminal's Table
Products
Cellular Product
Bands (Hz)
Data Speed
Supported Embedded Programming

3G/UMTS
HE910T-3G
HE910 Family
850/900/18001900/2100
3.75G 5.76/21.00
3.5G 5.76/7.2
3G 384/384
2G 118.4/236.8

4G/LTE
LE910T-4G
LE910 Family
850/9001/1800/1900/2100/2600
4-4.5G 50/100

GSM/GPS/GPRS
GE864T-GPS
GE864-GPS
850/9001800/1900
2G 40/80

GSM/GPRS
GL865T-DUAL
GL865-DUAL
900/1800
2G 40/80

GSM/GPRS
GE910T-QUAD
GE910-QUAD
850/9001800/1900
2G 40/80

Mini-IoT-910-2G
General Features
Dimension : 70 x 55 x 26 mm
Terminal Type : GSM/GPRS Terminal
Band : Quad-band EGSM 850/900/1800/1900 MHz
Supply Voltage Range : 5V-30V
Operation Temperature : -40 °C to +85 °C
Weight : 100gr
Embedded Programming
: Python 2.7.2 and C-Programming (Appzone)
Control via AT commands  : GSM 27.005 ,27.007 and Telit custom AT Commands
Interfaces : SIM, RS232, 4 I/O Ports, Antenna, RS485, ADC, USB
Other Features : Run AT Remotely, Embedded FTP & SMTP Client, Embedded TCP/IP Stack
GPS Option : Yes
WatchDog Option : Yes
